SUNERGY LINEAR PERFORMANCE WARRANTY:
● 12 Years Manufacturing Warranty
● 12 Years 94.6% Power Output
● 30 Years 87.4% Power Output
Sunergy Advantages
The 570W SUNERGY Mars Solar Panel is a 580W TOPCon Bifacial Half-Cut Solar Panel module with 144 cells from sunergy Solar, one of the leading manufacturers in photovoltaic solutions and present. This 580W Bifacial solar panel has a 12 year product warranty and 30 year linear power warranty, with efficiencies ranging from 87.4% to 94.6%.
Electrical Characteristics |
||||||||||
| Module Type | 560W | 565W | 570W | 575W | 580W | |||||
| STC | NOCT | STC | NOCT | STC | NOCT | STC | NOCT | STC | NOCT | |
| Maximum Power At STC(Pmax) | 560W | 422.7W | 565W | 426.5W | 570W | 430.2W | 575W | 434W | 580W | 437.8W |
| Short Circuit Current(Isc) | 14.04A | 11.40A | 14.11A | 11.46A | 14..18A | 11.52A | 14.26A | 11.58A | 14.33A | 11.64A |
| Open Circuit Voltage(Voc) | 50.72V | 48.04V | 50.87V | 48.18V | 51.02V | 48.32V | 51.17V | 48.47V | 51.32V | 48.61V |
| Maximum Power Current(Impp) | 13.28A | 10.78A | 13.35A | 10.83A | 13.42A | 10.89A | 13.49A | 10.95A | 13.56A | 11.00A |
| Maximum Power Voltage(Vmpp) | 42.18V | 39.22V | 42.33V | 39.37V | 42.48V | 39.52V | 42.63V | 39.65V | 42.78V | 39.79V |
| Module Efficiency | 21.70% | 21.90% | 22.10% | 22.30% | 22.50% | |||||
| Power Tolerance | 0～+5W | |||||||||
| Maximum System Voltage | VDC 1500V | |||||||||
| Maximum Series Fuse | 30A | |||||||||
| Increased Snowload Acc.to lec 61215 | 5400Pa | |||||||||
| Operating Temperature | -40～+85℃ | |||||||||
| Number of Bypass Diodes | 3 | |||||||||
| Norminal Operating Cell Temperature(Noct) | 45℃±2℃ | |||||||||
| Temperature Coefficient of Pmax | -0.3%℃ | |||||||||
| Temperature Coefficient of Voc | -0.25%℃ | |||||||||
| Temperature Coefficient of Isc | 0.046%℃ | |||||||||
| STC (standard test environment): irradiance 1000W/m², battery temperature 25°C, spectrum AM1.5 NOCT (normal battery operating temperature): irradiance 800W/m², ambient temperature 20°C, spectrum AM1.5, wind speed 1m/s. |
||||||||||
| Electrical Characteristics With Different Rear Side Power Gain | ||||||||||
| Backside Power Gain | 10% | 15% | 20% | 25% | 30% | |||||
| Maximum Power At STC(Pmax) | 621.5 | 650 | 678 | 706 | 734.5 | |||||
| Short Circuit Current(Isc) | 15.48 | 16.18 | 16.87 | 17.55 | 18.25 | |||||
| Open Circuit Voltage(Voc) | 51.07 | 51.27 | 51.47 | 51.67 | 51.87 | |||||
| Maximum Power Current(Impp) | 14.61 | 15.27 | 15.91 | 16.56 | 17.21 | |||||
| Maximum Power Voltage(Vmpp) | 42.55 | 42.58 | 42.61 | 42.64 | 42.67 | |||||
Sunergy has three production bases, the annual production capacity of photovoltaic modules is 8GW, annual production capacity of cells is 8GW, and annual installation capacity of photovoltaic power stations is 2GW.
